2.0 Repair instruction

You’ve loaded a CD into your CD-player, but the player doesn’t play it. What can you do? Those of you owning a 2-channel oscilloscope (or those who can borrow one) can try to get the CD-player started quite easily. But even without an oscilloscope you can take remedial action - e.g., if you follow the chapters Cleaning the lens and Increasing the laser current mentioned below.
The following should be said to alcohol: isopropyl alcohol can be bought at the chemist’s where it is very cheap. Ethyl alcohol would be an alternative; it is comparable, but much more expensive. Ethyl alcohol is drinkable, isopropyl alcohol is not. A certain substance makes it undrinkable. It’s the same with methylated spirit. For our purposes, the cheap alcohol will do. Isopropyl alcohol will leave a white thin coating on the surface of the lens after it is evaporated. This is the substance mentioned above. However, it is no problem; you can simply use the dry end of a cotton bud to wipe it off. The lens will be clean then.
Another problem can occur: The disk drive doesn’t rotate at all. In such a case the motor can be faulty (actually this is seldom the case) or the focusing doesn’t function any more. The latter can easily be checked: Hold a CD quite near the lens and check if the lens moves up and down. If this is the case the CD-player tries to find the optimum focusing, i.e., focusing functions correctly. Mostly, the following 3 reasons are responsible for the main defects:

    Laser (lens) is dirty
    Laser is not strong enough
    The device needs to be readjusted

If you have checked or cleared these 3 error sources and the CD-player still doesn’t function, certainly, the laser must be replaced. This, however, isn’t worth if the player cost about 100 Euro.
In the following, I will explain step by step how you can try to get the CD-player started and work properly.
Basically: If you change the position of the potentiometers, mark the original position before. I also like to turn the potentiometers but if, e.g., I turn more than 1 potentiometer I often forget the original position of each of them: one potentiometer adjusted incorrectly can disable the entire CD-player.

    Cotton buds (ear swabs)
    Isopropyl alcohol
    Screwdriver (for recessed-head screws)
    Small screwdriver (for slotted screws)
    a small marker or white marker, edding
    One 2-channel oscilloscope for the alignment

    The CD-player doesn’t recognize the loaded CD
    The CD-player recognizes the CD, but doesn’t play it
    The CD-player doesn’t play all songs
    The CD jumps while it is played

2.1 Cleaning the lens

First of all you have to remove the cover of the casing to clean the laser lens. You might have to remove the hplastic part above the laser to reveal the lens. This part is mostly fixed with plastic catches and may be connected with a spring. The following figure shows a Pioneer CD-player. The plastic part (1) has to be removed using the two plastic catches (2). Take a small screwdriver and push the catches to the left. At the same time, slightly lift the plastic part (1).

After the cover has been removed you can see the laser unit with the lens (1) (see figure 1-2). You can also see a part of the flat cable and the longitudinal guide of the laser. On the left and on the right side a rod (2) is situated. Two rings made of plastic (3) surround each rod (2).
The following figure shows this very clearly. A good lubrication ensures a smooth guiding. See also chapter Mechanical alignment.

Now the lens is uncovered. Use a cotton bud and pure alcohol or methylated spirit to clean the laser. Please do not use vodka or something similar (as vodka contains additives the lens would be soiled). Take the cotton bud and wipe the lens carefully: The lens is supported by a spring. If you press the lens too strongly it may not get back to its original position. The laser would be faulty then. Use the dry end of the cotton bud to complete the cleaning. Afterwards you can try if the CD-player functions. If not continue with the next chapter.

2.2 Increasing the laser current

The laser current has to be increased. Depending on the type of the CD-player the measuring points are on the big printed circuit board. Sometimes the measuring points are pins. In the case of the Sony CD-player the measuring points are jumpers with a big splodge of solder in the middle. Other CD-players do not have something similar. The measuring point "HF" or "EFM" must be looked for. This is not easy in some cases because some devices do not have points at all. The following figure shows a Technics CD-player. The measuring points are jumpers/wire straps. Jumper no. 1 is the "GND", jumper no. 2 has the signal "EFM" and jumper no. 3 is the jumper where you can measure the signal "Focus Offset".
If you do not find a measuring point look at the oscillogram and search on the ICs until you’ll see the signal. The characteristic is that the beams are bundled in the middle. What you cannot see in the figure is that a lot of sinusoids are lying on top of each other. Here they are displayed only blurred.

NOTE The HF signal is mostly positioned where the main printed circuit board is connected to the laser via the flat cable.

NOTE Unfortunately, the laser life is reduced by increasing the laser current. However, this is mostly the last option.

As soon as you have found the signal increase the laser current. The appropriate potentiometer (1) is positioned either directly on the laser or on the flat cable connecting the laser unit with the big printed circuit board. The following figure shows the potentiometer clearly.
After you have found the potentiometer turn it very carefully! and, simultaneously, observe the HF-signal.

ATTENTION If you turn up the potentiometer too quickly the laser might get too much current and the laser diode will break. Therefore turn it only slightly observing the oscillogram. Potentiometers are often sealed with lacquer. Turning the potentiometer can cause an uncontrolled jerk.

he amplitude must increase. In most cases this is sufficient. If the potentiometer has already reached its limit stop then this is quite suspect. Even if the CD-player is functioning now you can assume that it won’t last long. A potentiometer at its limit stop is never good. If this procedure hasn’t helped to get the CD-player working an alignment is necessary (see the following chapter).

2.3 Alignment of the CD-player

Principally, there are two different types of CD-players. The older versions have got potentiometers on their printed circuit board. The following figure shows the printed circuit board of a Technics CD-player.
You can clearly see the yellow potentiometers (1, 2 and 3) which are used for the alignment. On newer CD-players the alignment is done automatically. So, if your CD-player is a modern one, you cannot in fact do much. I assume that you have got a device with all the following potentiometers:

    TG (Tracking Gain)
    TO (Tracking Offset)
    TB (Tracking Balance) isn’t always available!
    FG (Focus Gain)
    PDB (Best eye) in Technics devices!

Furthermore, we need a test CD and a black gum tape approx. 0.9 mm broad and impervious to light. This must be adhered to the bright side of the CD.

NOTE The tape must not pass through the middle of the CD. Otherwise the CD might not be recognized [the information is in the inner edge of the CD (TOC-track)].

Here is a picture with my test CD. After the CD has been prepared as described before, insert it into the CD player. The potentiometer positions/adjustments are marked. What’s important now is if the CD player can read the CD at least. If no reading is possible this alignment cannot take place. The entire laser could be defective. In order to check this, get all potentiometers into center position. Then take the CD from the drawer and check with the naked eye if a red beam can be seen in the laser. The laser beam is a dark red point and you should see it on the surface of the lens if you look onto the lens slanting your head.

CAUTION Do not look directly or for a prolonged time into the laser beam, just glance at it. The laser is very weak but can, however, cause health damages. See also laser classes in the appendix.

Now connect channel A of the oscilloscope to "HF" and channel B to the measuring point "Focus Offset". If you do not find this point look for it until you see an oscillogram showing small square pulses (the square pulses are the black stripes on the CD). This figure shows the oscillogram. Next the "Focus Gain" will be set. If you turn up the appropriate potentiometer, you can hear how the lens grinds on the CD. Turn the potentiometer back until "grinding" noise stops. If you turn too much the CD player stops. Perform the same procedure with potentiometer "Tracking Gain" and afterwards with potentiometer "Focus Offset". HF dropouts should now be visible. There must not be any time shifting. Perform this procedure with potentiometer "Tracking Offset". If your CD-player has got the potentiometers "PDB" and "E-F-Balance", set them so that the HF looks as clear as possible, i.e., shows as little film as possible. If the CD-player doesn’t function yet repeat this alignment or reset one of the potentiometers.
You can assume that 80 % of the CD-players will function after the instructions mentioned above have been followed. If your player is one of the remaining 20 %, it is uncertain if a new laser unit is worth to purchase. In fact, I cannot claim that the player doesn’t function only because of the faulty laser. If the player is still faulty I would suggest to take it to a specialist shop or to someone else who knows a lot about CD-players. A further test is described in the chapter Mechanical alignment. This chapter deals with the mechanical alignment. Just a comment to the electrical alignment: The service manuals often describe how to activate the service mode. Sometimes this mode is quite helpful: you can check the laser without inserting a CD. The service mode of a Pioneer CD-player is activated as follows:
Eject the CD and switch off the CD-player. Press the small key button (1) on the main printed circuit board and keep it pressed. Switch off the CD-player. Using the buttons Forward, Reward and Play you can start the focusing process without an inserted CD and you can move the laser unit back and forth completely. Eject CD and switch off CD-player. In this way you can easily approach the lens. This figure shows the small key button:

Finally a short comment for adjusting the potentiometers: As man hours in production are very expensive Philips decided to go a different way. A CD-player was produced. Then it was aligned optimally. The potentiometers‘ positions/adjustments were photographed for the alignment regulations. This made is easy to set the potentiometers on every new CD-player. I do not know if the players were tested afterwards. If 5 of 100 CD-players were sent back because they didn’t function due to a wrong alignment this was okay for the company. These players were scrapped, the customer got a new player. An alignment would have been too expensive. If this is still practiced nowadays I do not know. Anyone who knows something about it can send me a comment if he/she likes.

2.4 Mechanical alignment

n the previous sections we assumed that the mechanics wasn’t misadjusted and a mechanically perfect CD was inserted into the Disc tray. Another reason for the CD player not functioning properly is an unbalanced CD or a slightly misadjusted mechanics. Unfortunately, the mechanical alignment cannot be described generally for all CD players. Anyone who wants to perform a mechanical alignment must order the service manual for his/her CD player. However, not every service manual describes a mechanical alignment. It might be better to contact the manufacturer to get information if there is a description available at all. It is worth asking since the prices for a service manual can amount to 30 Euro. See the appendix for addresses of companies that offer schematic diagram.
If an unbalanced CD has been inserted it must be replaced by a perfect one. If you use an oscilloscope to look at the HF you will see the amplitude pumping (voltage height). This pumping must be reduced to a minimum.
In order to function perfectly the mechanics has to be greased. The laser is moved over the whole area via two rods that are mounted sideways it. The laser is powered by spindle that is driven by a motor. Those rods and the spindle are greased. If the is not enough grease or it resinified new grease has to be used for re-greasing. A good brand for greasing is "Ballistol". Simply use an ear swab for putting some grease on the rods and make sure the motor moves the laser from one side to the other, and this way spreads the grease consistently. This might happen by putting a 80 min CD into the player.
